Water Leak Detection

A smart water shut-off valve designed with state-of-the-art ultrasonic technology to manage your entire home water system.

The StreamLabs Control shut-off valve is installed directly into your main water line and sends ultrasonic sound waves, recording the time delay to measure water flow and detect potential problems. It sends this data in real-time to the StreamLabs app via Wi-Fi, so you always know what’s happening —protecting your home 24/7 no matter where you are.

Some Things Can’t Be Replaced.

Don’t Let Leaks Take Them from You

It doesn’t matter where you live or what your home’s value is – no one is immune to damage caused by water leaks. In fact, water damage insurance claims are 3 times more common than theft and fire combined.

Water damage repair and cleanup costs can be significant, but the cost goes well beyond your insurance deductible. Leaks can destroy irreplaceable sentimental items, and can result in months away from home for your family while repair and renovations are being completed. Your insurance premium may increase, or your coverage could be dropped entirely. Memories and security can be lost in a matter of minutes.

The good news? This upheaval of your life is avoidable if you catch leaks in time.

40%

Of homeowners experience water damage *

1.3 Trillion Gallons

Water wasted annually by household leaks. **

$12,514

Average insurance claim for water damage. *

* Insurance Innovation Institute claim frequency 2017-2021
** EPA WaterSense household statistics 2023

Drip Detect™

Drip Detect™ is the Control's way of checking your plumbing for small, easy-to-miss leaks which produce so little flow they would otherwise be undetectable. An old or damaged toilet fill valves, corrosion in copper pipes, a loose connection in an appliance such as a washing machine or ice maker, or a dripping faucet can all cause these easy-to-miss leaks.

How Drip Detect™ Works

Select when and how often you'd like the Control to perform the Drip Detect test. It can be scheduled for any day at any time. For example, you can set it to run on the first of every month, every Tuesday, or even every day. It’s important to note that the default setting for Drip Detect is set to “On” for the 1st day of every month at 3:00 AM EST.

At the scheduled time, the Control will close the valve for up to 10 minutes. If you happen to use water during the test, the Control will automatically open the valve and postpone the test. The Control will try to perform the test again an hour later. The Control uses a combination of information including pressure and flow within your pipes to determine whether there may be water loss from your plumbing system (e.g. a pinhole leak or dripping faucet). At the end of the test, the Control will reopen the valve and send you a notification if an issue was detected. With Drip Detect, you are secure in knowing that even the smallest of problems in your home plumbing won't escape your notice.

The Perfect Installation

THINGS TO CONSIDER:

Wi-Fi Signal

Before installation, check your Wi-Fi signal strength at the location of the main water line. The Control needs a 2.4ghz Wi-Fi connection so it can send you alerts.

Installation Location

Your device will need access to an electrical outlet within 10 feet to power on (extension cables up to 100 feet available). It will also need a place on the main water line before any branches to other appliances and after the shut-off valve and pressure-reducing valve (PRV). The device may not be installed outside uncovered, but it may be installed in crawlspaces, garages, sheds or weatherproof NEMA enclosures where it is also protected from UV exposure.

  • Dimensions: 8.0" (L) x 3.5" (W) x 5.4" (H)
  • Weight: 3.5 lbs (not including fittings)(H)
  • Warranty: 1 year limited product warranty
  • App Compatibility: iOS, compatible with iPhone or iPad, Android, compatible with phone or tablet*
  • Low-Flow Detection: 0.1 gpm low-flow detection
  • Compatible Pipe Sizes: 3/4", 1", 1-1/4" Copper Tube Size (CTS) – Depending on fittings
  • Compatible Pipe Types: FNPT Threaded Connection: Any pipe type SharkBite®Connection:PEX, copper, CPVC, PE-RT**
  • Universal Power Supply: Input: 100-240VAC~50/600Hz, 0.5A;Output:12 V @ 1 A UL Listed 10’ cord included, 25’ & 50’ extension cable sold separately max distance 100’
  • Power Supply Length: 10 ft.(additional extension cables available for purchase, 25 & 50 ft.)
  • Water Temperature: min. 40°F (4.4°C) / max. 105°F (40°C) for optimal flow accuracy
  • Operating Pressure: max. 200 psi (14 bar) Limited by Pipe
  • Ambient Temperature: min. 32° F (0° C) / max. 115° F (46.1° C)for optimal flow accuracy
  • Operating Environment: Indoor use only.May be installed outdoors with a NEMA approved enclosure
  • IP Rating: IP 54 / 56 Rating***
  • Network: Wi-Fi 802.11b/g/n, 2.4 GHz

*Contact StreamLabs support for most up-to-date compatible version
**1-1/4" SharkBite fitting not approved for PE-RT use
***IP 54 rated for indoor use, IP 56 rating achievable with outdoor NEMA approved enclosure

Product Detection Settings

  • Slow Leak: 0.1, 0.25, 0.5, 1.0 GPM for 1, 5, 10, 15, 20, 30, or 60 mins
  • Major Leak: 2, 3, 4, 5, 10, 15 GPM for 5s, 30s, 1, 5, 10, 20, or 30 mins
  • Away Mode: Flow above 0.1 GPMThat lasts longer than 5s, 15s, 30s, 1, or 5 mins
  • Smart Alert: Control can learn usage habits, notify of any abnormal usage and shut off the water (optional)
  • Drip Detect™: Daily, Weekly, or Monthly Test (user configurable)
  • Pressure Alert: LOW: 10 psi, 20 psi, 30 psi, 40 psi for 1 minHIGH: 70 psi, 80 psi, 90 psi, 100psi for 1 min
  • Humidity Alert: LOW: 20%, 25%, 30%, 35% for 5 minsHIGH: 50%, 60%, 70%, 90% for 5 mins
  • Water Temperature Alert: LOW: 50°F, 45°F, 40°F, 35°F for 1 minHIGH: 90°F, 95°F, 100°F, 115°F for 1 min
  • Ambient Temperature Alert: LOW: 50°F, 45°F, 40°F, 35°F for 5 minsHIGH: 90°F, 100°F, 115°F, 120°F for 5 mins

*These settings are subject to change with updated software versions

Listings and Approvals

  • NSF/ANSI-61, NSF/ANSI-372, FCC, IC
